Engine
- Engine BrandCub Cadet®
- Engine ModelIntelliPOWER®
- Engine Model NumberAX90Z0
- Engine Displacement547cc
- Starter TypeElectric
- Fuel Tank Capacity3.5 gal. US (13.25 L)
- CylindersSingle
- Engine StartIgnition Key
- Engine Oil Capacity1.8 qt. US (1.7 L)
- LubricationFully pressurized
- Charging System12 amp regulated
- Fuel GaugeNo
- GovernorElectronic
- ChokeElectronic
- Air FilterDual element
- Oil FilterYes
- Fuel DeliveryCarburetor
Battery
- Battery230 CCA
- Battery TypeLead Acid
- Battery Voltage12V
Drive System
- TransmissionHydro-Gear EZT 2200
- Forward Speed7 MPH / 11.3 km/h
- Reverse Speed3.5 MPH / 5.6 km/h
- Drive SystemHydrostatic
- Serviceable TransmissionNo (Maintenance-Free)
Cutting Deck
- Deck Cutting Width42 in
- Deck WashYes
- Deck Material13-gauge steel
- Deck Engagement (PTO)Electric
- Deck ConstructionStamped
- Blade(s)Two
- Deck LiftFoot pedal with Dial Adjust
- Cutting Height Range1” – 4.5”
- Anti-ScalpingTwo gauge wheels
- Deck Positions15
Chassis
- Frame2” x 2” tubular steel
- Turning Radius0°
- ROPSNo
- Rear Tow HitchNo
- Corrosion ProtectionYes
- Front Caster Yokes1/4″ Steel
Controls
- Cruise ControlNo
- BrakesDisc
- Steering ControlLap Bars
Comfort
- Seat Type18″ high back
- ArmrestsNo
- Seat AdjustmentKnob
- Front Caster SuspensionNo
Wheels
- Rear Tires20”x 8”-8″
- Front Tires11″x 6″-5″
- Tire TreadTurf Master / Multi Trac
Specifications
- SeriesUltima Series™ Z
Additional Specifications
- Hour MeterAvailable Separately
- Mulch KitAvailable separately
- Headlight(s)No
- Cup HolderYes
- Operator Presence SystemYes
- Parking BrakeLap Bar Integrated
- Model Number17ALEACS010
Warranty
- Residential Warranty3-year unlimited hours
- Frame WarrantyLifetime Limited
- Deck Shell Warranty3-year unlimited hours
- Commercial WarrantyNo
Disclaimers
- SpecificationsSpecifications subject to change without notice and without incurring obligation. Products depicted on website and other advertisements are for demonstration purposes only. Actual products offered for sale may vary in design, required attachments, safety features and non-functional appearance from. See other general disclaimers at the bottom of our website.
- IntelliPOWER®*When compared to a Cub Cadet® 547cc engine without IntelliPOWER® feature (4X90HW) Improvements vary depending on engine models and specific operating conditions.
- Efficiency**Mowing identical grass conditions using a 42-inch Ultima Series zero-turn mower at a speed of 7 MPH vs. a Cub Cadet® 42-inch lawn tractor at a speed of 5 MPH.
